Chi tiết sản phẩm
Nguồn gốc: Wenzhou, Trung Quốc
Hàng hiệu: ZHE HENG
Chứng nhận: BV, PED, ISO9001
Model Number: JIS SUS304L，ASME S30403
Tài liệu: Sổ tay sản phẩm PDF
Điều khoản thanh toán và vận chuyển
Số lượng đặt hàng tối thiểu: Có thể thương lượng
Giá bán: $1000-4200/Ton
Packaging Details: As to clients' requirements，Wooden Cases，Bundle Packin
Delivery Time: 100TONS/30-45 work days
Điều khoản thanh toán: L/C, T/T, D/P, D/A
Khả năng cung cấp: Hơn 1000
Term Name: |
U Shape Steel Bending welded stainless steel |
Material Grade: |
JIS SUS304L，ASME S30403 |
hình dạng: |
Ống tròn, ống vuông, ống hình chữ nhật |
Kỹ thuật: |
cán nguội, cán nóng |
Length: |
3500mm Or 11000mm |
Kích cỡ: |
Theo yêu cầu |
Loại đường hàn: |
liền mạch / hàn |
Term Name: |
U Shape Steel Bending welded stainless steel |
Material Grade: |
JIS SUS304L，ASME S30403 |
hình dạng: |
Ống tròn, ống vuông, ống hình chữ nhật |
Kỹ thuật: |
cán nguội, cán nóng |
Length: |
3500mm Or 11000mm |
Kích cỡ: |
Theo yêu cầu |
Loại đường hàn: |
liền mạch / hàn |
Overview:
Stainless steel bending pipe is bent by using a complete set of bending equipment, which is divided into two processes: cold simmering and hot pushing. No matter what kind of machinery and equipment and pipelines, most of them are used for bending pipes, mainly for oil transmission, gas transmission, transfusion, engineering bridge construction and so on.
Specification:
(1)Carbon steel: ASTM/ASME A234 WPB, WPC
(2)Alloy: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP911, 15Mo3 15CrMoV, 35CrMoV
(3)Stainless steel: ASTM/ASME A403 WP 304-304L-304H-304LN-304N
(4)ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti
(5)ASTM/ASME A403 WP 321-321H ASTM/ASME A403 WP 347-347H
(6)Low temperature steel: ASTM/ASME A402 WPL3-WPL 6
(7)High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-70
(8)Cast steel, alloy steel, stainless steel, copper, aluminum alloy, plastic, argon, PVC, PPR, RFPP(reinforced polypropylene) and so on.
(9)Aluminum alloy 3003,6061, copper, copper, brass
| Approximate Comparative Table | |||||||
| ASTM/ASME | ISO | USA | JAPAN | BRITAIN | GERMANY | CNS | |
| UNS No. | AISI | JIS | BS | WERKSTOFF DIN | |||
| S30400 | 11 | 304 | SUS304 | 304S31 | 1.4301 | X5CrNi1810 | 304 |
| S30403 | 10 | 304L | SUS304L | 304S11 | 1.4306 | X2CrNi1911 | 304L |
Stainless Steel Seamless Pipe Chemical Component:
The JIS SUS304L chemical component
| Chemical Composition about stainless steel pipe | |||||||
| Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ |
| JIS SUS304 | 0.08 | 0.75 | 2 | 0.045 | 0.03 | 8.00-11.00 | 18.00-20.00 |
| JIS SUS304L | 0.035 | 0.75 | 2 | 0.045 | 0.03 | 8.00-13.00 | 18.00-20.00 |
Size table:
Seamless stainless steel pipes
| WALL THCKNESS FOR STAINLESS STEEL PIPE &T UBE (ASME B36.10 & B36.19) | |||||||||||||||
| DNmm | DNin | φmm | SCH5S | SCH10S | SCH40S | STD | Sch40 | Sch60 | Sch80s | XS | Sch80 | Sch120 | Sch140 | Sch160 | XXS |
| 6 | 1/8 | 10.3 | 1.24 | 1.73 | 1.73 | 1.73 | 2.41 | 2.41 | 2.41 | ||||||
| 8 | 1/4 | 13.7 | 1.65 | 2.24 | 2.24 | 2.24 | 3.02 | 3.02 | 3.02 | ||||||
| 10 | 3/8 | 17.1 | 1.65 | 2.31 | 2.31 | 2.31 | 3.2 | 3.2 | 3.2 | ||||||
| 15 | 1/2 | 21.3 | 1.65 | 2.11 | 2.77 | 2.77 | 2.77 | 3.73 | 3.73 | 3.73 | 4.78 | 7.47 | |||
| 20 | 3/4 | 26.7 | 1.65 | 2.11 | 2.87 | 2.87 | 2.87 | 3.91 | 3.91 | 3.91 | 5.56 | 7.82 | |||
| 25 | 1 | 33.4 | 1.65 | 2.77 | 3.38 | 3.38 | 3.38 | 4.55 | 4.55 | 4.55 | 6.35 | 9.09 | |||
| 32 | 1 1/4 | 42.2 | 1.65 | 2.77 | 3.56 | 3.56 | 3.56 | 4.85 | 4.85 | 4.85 | 6.35 | 9.7 | |||
| 40 | 1 1/2 | 48.3 | 1.65 | 2.77 | 3.68 | 3.68 | 3.68 | 5.08 | 5.08 | 5.08 | 7.14 | 10.15 | |||
| 50 | 2 | 60.3 | 1.65 | 2.77 | 3.91 | 3.91 | 3.91 | 5.54 | 5.54 | 5.54 | 8.74 | 11.07 | |||
| 65 | 2 1/2 | 76 | 2.11 | 3.05 | 5.16 | 5.16 | 5.16 | 7.01 | 7.01 | 7.01 | 9.53 | 14.02 | |||
| 80 | 3 | 88.9 | 2.11 | 3.05 | 5.49 | 5.49 | 5.49 | 7.62 | 7.62 | 7.62 | 11.13 | 15.24 | |||
| 90 | 3 1/2 | 101.6 | 2.11 | 3.05 | 5.74 | 5.74 | 5.74 | 8.08 | 8.08 | 8.08 | |||||
| 100 | 4 | 114.3 | 2.11 | 3.05 | 6.02 | 6.02 | 6.02 | 8.56 | 8.56 | 8.56 | 11.13 | 13.49 | 17.12 | ||
| 125 | 5 | 141.3 | 2.77 | 3.4 | 6.55 | 6.55 | 6.55 | 9.53 | 9.53 | 9.53 | 12.7 | 15.88 | 19.05 | ||
| 150 | 6 | 168.3 | 2.77 | 3.4 | 7.11 | 7.11 | 7.11 | 10.97 | 10.97 | 10.97 | 14.27 | 18.26 | 21.95 | ||
| 200 | 8 | 219.1 | 2.77 | 3.76 | 8.18 | 8.18 | 8.18 | 10.31 | 12.7 | 12.7 | 12.7 | 18.26 | 20.62 | 23.01 | 22.23 |
| 250 | 10 | 273 | 3.4 | 4.19 | 9.27 | 9.27 | 9.27 | 12.7 | 12.7 | 12.7 | 15.09 | 21.44 | 25.4 | 28.58 | 25.4 |
| 300 | 12 | 323.8 | 3.96 | 4.57 | 9.53 | 9.53 | 10.31 | 14.27 | 12.7 | 12.7 | 17.48 | 25.4 | 28.58 | 33.32 | 25.4 |
| 350 | 14 | 355.6 | 3.96 | 4.78 | 9.53 | 11.13 | 15.09 | 12.7 | 19.05 | 27.79 | 31.75 | 35.71 | |||
| 400 | 16 | 406.4 | 4.19 | 4.78 | 9.53 | 12.7 | 16.66 | 12.7 | 21.44 | 30.96 | 36.53 | 40.49 | |||
| 450 | 18 | 457 | 4.19 | 4.78 | 9.53 | 14.27 | 19.05 | 12.7 | 23.83 | 34.93 | 39.67 | 45.24 | |||
| 500 | 20 | 508 | 4.78 | 5.54 | 9.53 | 15.09 | 20.62 | 12.7 | 26.19 | 38.1 | 44.45 | 50.01 | |||
| 550 | 22 | 559 | 4.78 | 5.54 | 9.53 | 22.23 | 12.7 | 28.58 | 41.28 | 47.63 | 53.98 | ||||
| 600 | 24 | 610 | 5.54 | 6.35 | 9.53 | 17.48 | 24.61 | 12.7 | 30.96 | 46.02 | 52.37 | 59.54 | |||
| 650 | 26 | 660 | 9.53 | 12.7 | |||||||||||
| 700 | 28 | 711 | 9.53 | 12.7 | |||||||||||
| 750 | 30 | 762 | 6.35 | 7.92 | 9.53 | 12.7 | |||||||||
| 800 | 32 | 813 | 9.53 | 17.48 | 12.7 | ||||||||||
Conforms to ANSI B36.19 and ANSI B36.10 standards
